Omega Audio Concepts MONO DNA

Technical characteristics

POWER SUPPLY MODULE 1 CHANNEL RIGHT 1 CHANNEL LEFT

• Toroidal transformers for the power supply section, preamplification, and volume control, independent for positive and negative half-waves.
• Separate toroidal transformers for positive and negative half-wave of the final stage power supply section.
• IEC inlet with fuse
• Maximum power consumption: 300 W for the right channel and 300 W for the left channel.
• Cabinet made from solid aluminum, machined using CNC technology.
• Dimensions: 255 x 255 x 80 mm (W x D x H)
• Weight: 10.5 kg. + 10,5 Kg.

AMPLIFICATION UNIT 1 module right channel 1 module left channel

• Cabinet made from solid aluminum, machined using CNC technology.
• Analog signal ground separated from power supply circuit ground
• SMD components with a tolerance of 0.1% for resistors and capacitors in the preamplification and amplification stages.
• No series capacitors in the signal path. Be careful not to connect the audio source with continuous output voltage higher or lower than 10 mV.
• Internal and external connection system made with patented ELEMENTS conductors from OMEGA AUDIO CONCEPTS
• Digital volume control with a single resistor in the signal path in 0.5 dB steps.
• Three high-level inputs with RCA connectors.
• Input impedance 10 kohm
• Power: 100W into 8 ohms, 170W into 4 ohms.
• Signal/noise ratio: 100 dB
• Volume control and input selector system with a remote control included, featuring a low-energy Bluetooth app for Android.
• Dimensions: 255 x 255 x 90 mm (W x D x H)
• Weight: 11.5 Kg. + 11,5 Kg.
