Technical Highlights

• Precision Oven Controlled Crystal Oscillator OCXO
• Adjustable Output Frequencies
• Small Form Factor

CLOCK-OUT (Fixed)

• 45.1548MHz x 2
• 49.152Mhz x 2

CLOCK-OUT (Adjustable)

• 44.1kHz, 48kHz
• 11.2896MHz, 12.288MHz
• 22.5792MHz, 24.576MHz

Output Connector

• BNC, 75ohms

AC Power Requirement: 100-240VAC, 50/60Hz (Manual Selector)

Power Consumption: ≤20W

Dimension: 340W x 260D x 66H mm (Feet +18mm)

Package Content: MCLK. No remote control & power cord.

Weight: 6 Kg

Color: Black/Silver

Warranty: 12 Months
