8-channel amplifier utilizing Adaptive Voltage Switching Power Supply technology with explosive power and ultra-low distortion.


  • Peak Power: 280W@4ohm, 170W@8ohm.
  • RMS power: 220W@4ohm, 120W@8ohm.
  • Multizone: Bus A, Bus B, and Line In.

The NuPrime-X MCX-800MZ is a multizone eight-channel amplifier that has four stereo modules, each with its own Adaptive Voltage Switching Power Supply technology and integrated amplifier incorporating highspeed gate driver error correction. This technology enables each module to deliver explosive power and ultra-low distortion, with a neutral and detailed sound characteristic. The MCX-800MZ has advanced protection circuitry that safeguards it from fault conditions such as short circuits, overload, overtemperature, and under-voltage.


The Adaptive Voltage Switching Power Supply is the most innovative SMPS design introduced by NuPrime. The amplifier’s output signal feeds back into the power supply’s servo power stage, causing a change in the output voltages supplying the power stage of the amplifier. This design resulted in more details at a low music level and explosive power at a high volume.


Read full description
View at Nuprime X
Specifications

WATT RECOMMENDS

Save your favorites. Compare them anytime.

Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.

Watt'n Potatoes

Not yet rated

This product doesn't have a Watt'n Potatoes score or editorial summary yet.

WATT RECOMMENDS

Save your favorites. Compare them anytime.

Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.

Reviews & Sources

Online Reviews & Mentions

No reviews found yet

store
store
store
store
store
store

YouTube Reviews

No reviews found yet

store
store
store
store

Forum Mentions

No forum mentions found yet

store
store
store
store
store
store

Specifications

Inputs
Switch L position : RCA analog input x 8 Switch B position : XLR analog input x 2 Switch A position : RCA analog input x 2 Trigger in (DC 0V~15V). Floating or (DC 3V~15V) as running ; less than 0.7V as standby.
Outputs
Stereo Speaker Out x 8 Line Out : XLR analog Out x 2 , RCA analog Out x 2 Trigger Out (12V,<0.1A) DC 5V Output via Type-A USB Connector (Maximum output 1.6A) x 2
Inputs switch
L: Each channel has an independent input (Line In) B: All inputs are transmitted through XLR cable (Bus B) A: All inputs are transmitted through RCA cable (Bus A)
Bus Function
Bus L: When the switch is in the L position (Line In), each channel has an independent input to drive each corresponding speaker output. Bus B : When the switch is in the B position(Bus B), all inputs are transmitted through Bus B XLR cable , the left channel drives speaker outputs 1, 3, 5, and 7, the right channel drives speaker outputs 2, 4, 6, and 8 and Bus Output can feed Bus Input of another MCX-800MZ. Bus A: When the switch is in the A position(Bus A), all inputs are transmitted through Bus A RCA cable , the left channel drives speaker outputs 1, 3, 5, and 7, the right channel drives speaker outputs 2, 4, 6, and 8 and Bus Output can feed Bus Input of another MCX-800MZ.
Amplifier
Power Output (Peak): THD+N 10% @ 4 Ohm @ 300W Power Output (Peak): THD+N 10% @ 6 Ohm @ 240W Power Output (Peak): THD+N 10% @ 8 Ohm @ 180W Power Output (RMS rated): THD+N 1% @ 4 Ohm @ 260W Power Output (RMS rated): THD+N 1% @ 6 Ohm @ 200W Power Output (RMS rated): THD+N 1% @ 8 Ohm @ 150W Input Impedance: 47k Ohms Gain Adjustable: Magnification x 17~x 32 is adjusted through variable resistor Signal to Noise Ratio: > 95dB at 1W, 10W, 100W THD+N: <0.005% Frequency Response: 10Hz to 50kHz Worldwide AC voltage: US Version 100 ~ 120Vac, Europe version 220 ~ 240Vac, AC voltage not switchable AC Fuse: Slow-blow, 15A/250V(US Version) , 10A/250V(Europe version) Dimension: 430 mm W x 330 mm D x 105 mm H (including feet) Weight: 10.5 kg Color: Black
Trigger Input
Trigger Output
Balanced Line Output

Manufacturer's Description — Nuprime X

8-channel amplifier utilizing Adaptive Voltage Switching Power Supply technology with explosive power and ultra-low distortion.


  • Peak Power: 280W@4ohm, 170W@8ohm.
  • RMS power: 220W@4ohm, 120W@8ohm.
  • Multizone: Bus A, Bus B, and Line In.

The NuPrime-X MCX-800MZ is a multizone eight-channel amplifier that has four stereo modules, each with its own Adaptive Voltage Switching Power Supply technology and integrated amplifier incorporating highspeed gate driver error correction. This technology enables each module to deliver explosive power and ultra-low distortion, with a neutral and detailed sound characteristic. The MCX-800MZ has advanced protection circuitry that safeguards it from fault conditions such as short circuits, overload, overtemperature, and under-voltage.


The Adaptive Voltage Switching Power Supply is the most innovative SMPS design introduced by NuPrime. The amplifier’s output signal feeds back into the power supply’s servo power stage, causing a change in the output voltages supplying the power stage of the amplifier. This design resulted in more details at a low music level and explosive power at a high volume.
