FiiO X7 MARK II

X7 Mark II

X7 Mark II

Thoroughly Transformed, Inside and Out

Bluetooth 4.2(aptX)

2.4/5G Wi-Fi

Hi-Res DAP

3.97 '' 480x800

Native DSD Support

3.5 SE+ 2.5 BAL

ES9028 PRO

2GB/DDR3L

8 Hours Battery Life

64GB ROM

QC2.0+MTK PE

Up to 256GB X 2

Copious 2GB RAM, 64GB of internal storage, and 2 micro-SD card slots

The X7 Mark II is among the first of its kinds in Chinese portable music players to adopt 2GB of RAM, allowing it to seriously multi-task and to provide a more fluid experience. The player also comes with 64GB of internal storage and 2 micro-SD card slots, each supporting up to 256GB expansion cards. This means that the X7 Mark II is able to hold up to a whopping 576GB of music, enough for  over 19,000 lossless music files, 30MB in size for each. With the X7 Mark II, you truly don't have to worry about leaving any of your music collection behind, wherever you go.

Flagship DAC brings more resolution, more dynamic range, more soundstage

The X7 Mark II employs the 8-channel ESS ES9028PRO DAC. With an exceptional signal-to- noise (SNR) ratio of 129dB and a remarkable total harmonic distortion plus noise (THD + N) figure of -120dB, this DAC is able to provide more resolving power, better dynamics, and better soundstage for greatly improved sound quality over its predecessor. When combined with the ability to skip Android's native audio re-sampling (ASRC) along with the ES9028PRO's unique THD compensation feature and special built-in filters, the X7 Mark II ensures that your music will sound sweet and musical, just like how it is supposed to.

All new amp module, serving up both balanced and single-ended flavors

Bundled with the X7 Mark II is the AM3A, an all-new amplifier module with both single-ended and balanced headphone outputs. The AM3A uses the widely-acclaimed AD8620 precision, wide bandwidth JFET operational amplifier as well as the tailor-made OPA926 op-amp, which was exclusively designed for the X7 Mark II to satisfy FiiO engineers' need for a high-performing part. Before settling on the AM3A's final design, over the course of a year's worth of intense internal and external testing, FiiO engineers went through three major design revisions as well as nine different PCB designs. It was only after this constant iteration that we could achieve a sound that we were truly satisfied with.

Three crystal oscillators for the ultimate reproduction of music

The X7 Mark II utilizes three separate crystal oscillators – one for the DSD and 44.1 kHz multiples sampling rates, and one for the 48kHz multiples sampling rates, as well as one for the 384 kHz sampling rate. Compared to the original X7, there are not only more crystal oscillators in the X7 Mark II but they also run at a faster rate. This guarantees that under all sampling rates there is radically reduced jitter, increased clock precision and stability, and overall more correct conversion from digital signals to analog.

Every last detail refined, all in FiiO's distinctive design language

The X7 Mark II is of a totally new design compared to the original X7, now with design elements from its little brother the X5 3rd gen. For instance, both the side-mounted volume wheel of the X7 Mark II with its etched 45° lines and the red ring that encompasses the power button are both inspired by similar touches on the X5 3rd gen. By giving the new X7 such unique flourishes, we solidify the link between the X7 Mark II and the X5 3rd gen as being part of the same, distinctive family of FiiO players. These are only some of the many details that have been thoroughly refined on the X7 Mark II to make it an exceptional portable music player.

Your eyes and fingers will thank you for in-cell touch technology

The high-definition 480*800 in-cell touchscreen of the X7 Mark II is a fantastic feast for your fingers and eyes, and also facilitates easy operation of the device.

Precisely-sized to ensure great handling

The weight and dimension of the X7 Mark II have been fine-tuned and further refined compared to the original in order to ensure that its feel in the hand is even better than before. When you pick the new X7 Mark II up, your hands will immediately know.

Length shortened by

1.2mm

Thickness reduced by

1.0mm

Weight reduced by

​​​​​​​10g

The sky's the limit with interchangeable amp modules

The X7 Mark II continues to adopt the highly flexible and groundbreaking interchangeable amp module design introduced by its predecessor. Though the new amp modules specifically designed for the new X7 are slightly different in design, the X7 Mark II is fully compatible with the original X7's various modules. Simply bolt on the included side mounts onto those amp modules and you are ready to listen!

A breakthrough in internal design yet again

Sleek lines with concealed micro-SD card slots

The concealed micro-SD card slots in the X7 Mark II are all-new, specifically designed to not only look beautiful but to also allow you to easily insert your expansion cards quickly and correctly.

In the making of the X7 Mark II, not only were better parts and hardware used, but also much thought was given to how to make a design of the internals both more reliable and less prone to EMI (electromagnetic interference). As a result, seven specific areas of the PCB are specially shielded, and there is even double shielding for the main control area and op-amps due to their importance in the maintaining excellent sound quality.

2 fast-charging technologies, so you can be 1 step ahead

Despite the X7 Mark II being thinner and lighter than its predecessor, it also packs a bigger, high -voltage fast-charging capable battery – now with a capacity of 3800mAh. And due to support for the popular QC2.0 and MTK PE quick-charging standards, the new X7 charges 2.7x faster than the original model. In merely the time it takes to watch a short movie (1.5 hours), you can fully top off the X7 Mark II's generous battery.

In a connected era, we expect a better wireless experience

Using Wi-Fi on the new X7 Mark II is a much better experience than on the original model, due to support of Wi-Fi on both the 2.4GHz and 5GHz frequency bands. This allows for more stable, stronger signal reception strength and faster speeds. In addition, FiiO has paid special attention to the internal design to ensure that all of your wireless signals, whether it be Wi-Fi, Bluetooth, etc., will not suffer from outside electromagnetic interference. All of this means that compared to the first generation, the new X7 is much better equipped to deal with EMI.

True wireless freedom with dual-mode Bluetooth

Yet even more flexibility with both optical and coaxial output

On top of the coaxial output the original X7 was capable of, the new X7 can now also output optical signals, taking the X7 to new heights in its already impressive flexibility.

Satisfy your need for speed with a deeply-customized Android 5.1

The X7 Mark II uses a version of Android 5.1 deeply customized and optimized from the core-level up for enhanced audio playback. Compared to stock Android 5.1, the version utilized in the new X7 is much faster and much less prone to freezing and stuttering for a silky-smooth experience.

Advanced automatic detection of lyrics and covers

The X7 is among the first of its kind in smart high-resolution lossless audio players to incorporate automatic detection and search of music lyrics and covers. No more having to manually search and download the correct album covers and lyrics for your tunes – saving you time and hassle.

A UI you'll fall in love with at first sight

Rejoice, UI lovers! The FiiO UI design team has specially created a new UI for the new X7, specifically optimized to be both stylish and functional in helping to get to your music quickly. The X7 Mark II also comes with three Android system-wide themes, which can be switched on the fly without having to restart the device. More themes created by FiiO will be available to download later on.

Simply intuitive device lock options

The X7 Mark II provides an intuitive interface that allows you to easily define which buttons and functions that are still active while the screen is off and locked, so you can effectively prevent accidentally unlocking your device.

More features for more control over your device

For the convenience of many customers, the Google Play framework, services, and related apps are pre-installed onto the X7 Mark II. But for those in areas where these services are not available, these apps and services can be removed to both free up space and to have less processes running in the background during normal usage.

A dock turns the new X7 into a desktop master

When at the office or at home, you can attach a special decorative accessory that will allow the X7 to be docked to the K5 – giving the X7 the flexibility to be a part of a desktop audio system that truly lets you enjoy your music.

Custom-made accessories that don't sacrifice function or form

Also included with every X7 Mark II is a leatherette case with a specially-chosen mix of materials. On the outside is leather with smooth outer grains that feel luxurious to the touch and great to handle, while on the inside there is synthetic leather material that helps to protect your investment in this unit.

Pre-applied onto every X7 Mark II is a 7H tempered glass screen protector with a 90%+ light transmittance rate. This particular screen protector is hard enough to be resistant against most scratches without compromising on how easily see-through it is.
