SW1x DAC III USB

SW1X DAC III USB

TDA1541 DAC with 6N6P Valve Output Stage & USB Input

The SW1X DAC III USB version is essentially a DAC III (Single Ended) with an integrated USB interface in full size chassis like the Balanced version just without signal OPTs, larger power supplies & power tube output stage.

Based on the legendary Philips TDA1541 DAC, the SW1X DAC III offers a harmonically rich and lush sound with improved dymanics over the predecessors. For maximum synergy, musical & analogue character, all Single-Ended & Balanced versions were designed to be paired with our VDT Digital Source products. However the DAC III USB offers a compact solution for those looking to have an integrated USB interface.

SW1X Audio Design™ DAC III USB Features:

• Pure & Elegant NOS (Non oversampling – zero digital domain filtering) R2R Design
• Highest Grade of TDA1541 DAC
• Balanced (& Single Ended) Signal Output Transformer (OPT) de-coupled Valve Output Stage Topology
• Zero NFB, Single Ended, Class A, Directly Heated Power Triode Valve Power Output Stage
• Quasi Dual Mono, Directly Heated Double Diode Valve Rectified B+ Power Supply
• Dynamic Element Matching (DEM) regulated by Valve Clock, powered by Valve Rectified & Choke Filtered Power Supply
• Discrete Transistor, Shunt Voltage Regulated Low Voltage Power Supplies

Specially Selected and Harmonically Matched Component & Material Quality

• M6 grain orient EI core Mains Transformers & Chokes
• Black Gate de-coupling Capacitors for TDA1541 DAC
• AN Copper Foil Signal Output de-coupling Capacitors
• Internally wired exclusively with our SW1X Magnum, Genesis and Opus conductors of various geometry (single strand or Litz)

DAC III is currently available in following versions:

• SE (compact chassis) + VDT Digital Source
• USB (with USB interface in larger, full size chassis)
• CDP III (with VDT 1/2 in full size chassis)
• BalancedVDT Digital Source

Tube Compliment

1 x 5Y3 1 x 6N6P 1 x E180F 1 x EAA91 E180F for SPDIF Output

SW1X Audio Design™ USB Interface Features:

• Discrete and Independently Transformer powered Master Clock – the Heart of Digital
• Output Stage for the SPDIF signal Output
• Discrete & independent Linear Power Supplies for CPU, Master Clock & Output Stages

Audio Playback

• Coaxial SPDIF Audio Output, PCM up to 192 kHz 24/32 bit
• AES/EBU Audio Output, PCM up to 192 kHz 24/32 bit
• USB Audio Output, PCM up to 768 kHz 32 bit
