SW1x DAC II Balanced Special

SW1X DAC II Balanced Special

PCM56 DAC with Active I/V 6V6 Valve Output Stage & Signal Output Transformer

The Balanced Special version is a top of the line & very special DAC II: it is the fusion of the DAC II Balanced and the DAC IV Special

This version shares the digital side of the DAC II Balanced, employes an active I/V conversions stage and borrows the 6V6 power tube output stage from the DAC IV

The 6V6 power tube output stage is de-coupled by a signal output transformer (OPT) de-coupled power tube output stage driven by the active I/V conversion stage for an even more dynamic bite.

SW1X Audio Design™ DAC II Balanced Special Features:

• Performance Level 3
• Pure & Elegant NOS (Non oversampling – zero digital domain filtering) R2R Design
• Balanced (& Single Ended) Signal Output Transformer de-coupled Valve Output Stage Topology
• Digital side is based on 4 x PCM56 (2x per channel) R2R DACs
• 6V6 Power Output Tubes, Zero NFB, Class A, Valve Output Stage
• Active I/V conversion via a special transistor (with less than 10 Ohm input impedance)
• Discrete Transistor, Shunt Voltage Regulated Low Voltage Power Supplies
• 5U4GYB/5R4GYB Directly Heated Valve rectified C2LC (choke filtered) B+ Power Supply

Specially Selected and Harmonically Matched Component & Material Quality

• Specially treated SW1X Audio Design 80% Nickel Mumetal Core Intefrace Transformer
• SW1X Audio DesignCopper wound Super HiB DC core Signal Output Transformers
• M6 grain orient EI core Mains Transformers & Chokes
• Internally wired exclusively with our SW1X Magnum, Genesis and Opus conductors of various geometry (single strand or Litz)
• AN Copper Foil in Oil interstage signal de-coupling Capacitors
• AB 2W non-magnetic Carbon film Resistors in selected places

Tube Compliment

2 x 6V6

1 x 5R4GYB

Optional Extras:

• Fully Hardwired Tube Output Stage on the Bakelite Board
• Fine Silver wiring on the Input, Bakelite Board and Output

DAC II is available in matte Black or satin Silver front fascia and following top panel options:

• Aluminum anodized in satin Silver or Black finish (standard)
• Brushed Brass (yellow glow)
• Brushed Pure Copper (orange glow)
• Paint Finishes any of the ones stated below:

a) Satin Audi Metallic Grey
b) Gloss Gunmetal Black
c) Gloss Porsche Guards Red
d) Black-Silver Hammered Vintage Paint finish

*Or any automotive paint on special request
