Features

• Impedance : 4 Ω
• Sensitivity : 96 dB
• Frequency Response (±1 dB) : 37 Hz – 20 kHz
• Power : 250 W
• Peak Power : 500 W
• Recommended Amplifier Power : 6 – 250 W

Transducers

• Tweeter : 1-inch Compression Driver
• Woofer
  • 16 cm paper membrane / Tangential suspension / Neodymium Eighteen Sound (front)
  • 13cm polypropylene membrane Eighteen Sound (rear)

Usage tips

Adjustable Bass Reflex Port

• Factory setting : 14.3 cm
• Adjustment options : Lengths of 14.5 cm, 16.1 cm or 17.0 cm may also give good results depending on your room.

Speaker Placement

• Supports being against the wall
