Theater-reference Dolby Atmos or DTS: X sound through up to 7.2.4 channels complements 8K HDR video passthrough. Connect 5.2.4-channel speakers and Zone 2 speakers and switch between 5.2.4-ch and 5.2.2-ch + Zone 2 playback or use 5 GHz/2.4 GHz Wi-Fi and your voice to control music all around your home.

State-of-the-art digital room correction technology improves overall audio performance across the full frequency band with no additional upgrade required. Dirac Live automatically calibrates sound in your room using either your smartphone and the included wired mic or go virtually wireless with the Dirac Live PC or MacOS* application, and a 3rd party USB mic (not included). Dirac Live unlocks your loudspeakers’ full potential in any listening space and delivers a uniquely pristine listening experience. Now, you will get a more accurate measurement of the positions of your Surround Sound system to be more precise and balanced to provide a better result with an increased the upper limit of delay time from 20 milliseconds to 50 milliseconds.

*Device must be connected to the internet and the same network as your AVR.

IMAX Enhanced

Hear the sound filmmakers intended. This IMAX Enhanced A/V receiver features DTS:X sound technology optimized for the IMAX® signature experience, reproducing the full dynamic range of IMAX theatrical sound-mixes available with digitally re-mastered IMAX Enhanced content. A pre-set IMAX Mode reproduces audio at the highest levels and delivers an unmatched IMAX sound experience. Requires a free firmware update.

THX Certified

THX spends 40-60 hours testing over 2000 data points ensuring that this receiver is capable of meeting rigorous audio and video performance standards for reference level, distortion free playback and includes THX Loudness Plus technology to bring out intricate details at lower listening levels.

Dolby Atmos Height Virtualizer

When playing any Dolby® format, engaging Dolby Atmos Height Virtualizer enables a more immersive listening experience, creating a virtual surround and height effect from traditional speaker layouts without the need for additional surround or height speakers.

Immersive three-dimensional sound

Supports Dolby Atmos and DTS:X for an immersive three-dimensional sound-space through 7.2.2 or 5.2.4 channels. Connect an outboard power amp via 11.2-multichannel pre-outs and enjoy seamless top-to-bottom, side-to-side, and front-back coverage with one or two pairs of in-ceiling or add-on module speakers, and seven bookshelf or tower speakers. Experience lifelike 360° sound from the real world in your personal home theater space.

Perfect for custom installation

Integra products are designed and engineered to meet the demands of leading custom installers. CI Centric features such as Web Setup, Onboard HDMI Diagnostics, and compatibility with Remote Monitoring systems like OVRC Pro and Domotz make Integra AVRs the choice of the modern integrator. Optional rack mount kits provide a clean, finished look when installed in racks and cabinets, while a unique bright white back panel facilitates connections in hard-to-reach areas.

Klipsch Optimize Mode

Klipsch Optimize Mode allows you to easily integrate your Klipsch Reference and Reference Premiere speakers seamlessly with your Integra AV receiver. Klipsch and Integra teamed up to implement precise crossover values for specific new Reference Premiere speakers. Now, you can simply select the model speakers you’ll be using for each individual channel, and the optimized crossover setting will be automatically applied.

Additional features

Aluminum front panel and volume knob

Front-to-Surround/Height speaker switching in Stereo Assign Mode

One-touch volume memory preset assignment to individual A/V inputs via front panel

OSD function displays A/V input signal data, output signal/settings data, and network information

Dolby® TrueHD and DTS-HD Master Audio® decoding

THX® listening modes for films, games, and music

Advanced Music Optimizer™ improves compressed audio playback quality

High-definition GUI over HDMI

Super Resolution 1080p to 4K and 1080p/4K to 8K video upscaling via HDMI

Crossover Adjustment (40/45/50/55/60/70/80/90/100/110/120/130/150/180/200 Hz)

A/V Sync Control (Up to 500 ms in 1 ms steps at 48 kHz)

Sleep timer, HDMI passthrough, and network standby

40 FM/AM/internet radio presets with station-naming (10 characters)

3-Mode display dimmer (Normal/Dim/Dimmer)

Integration features

Ethernet supports setup and IP control via a web browser

Works with Crestron®, Control4®, Savant, URC, ELAN, RTI and other major control systems

Works with OvrC Pro and Domotz Remote Monitoring systems

RS-232 input for external control and automation

2 IR inputs and 1 output

3 programmable 12 V trigger-outs with adjustable delay (A: 100 mA, B: 25 mA, C: 25 mA)

Dealer-settings memory storage and recall function

AC inlet for detachable IEC power cable

Optional rack-mount kit (IRK-180-4C)

Mounting

Compatible rack mount (optional)

IRK-180-4C
