Authorized dealers for Soundastic Amplifier DM 250

  • Hi Fi Mansion — in-store — Rivas-Vaciamadrid, Comunidad de Madrid, Spain (website)
Soundastic Amplifier DM 250 #1
Soundastic Amplifier DM 250 variant 1
Soundastic Amplifier DM 250 variant 2
Soundastic Amplifier DM 250 variant 3
Soundastic Amplifier DM 250 variant 4

Soundastic Amplifier DM 250

Poland flag

The harmonics and phase conversion system changes the proportions in the spectrum of harmonic distortion!


A world of music from the comfort of your own home!


STRUSS AUDIO DM 250

PRE IN SWITCH

Struss dual mono amplifier has been equipped with a PRE IN switch which means our device can act as a preamplifier and enables independent use of internal power amplifiers.


Amplifier modes: Phono, XLR, CD / DAC, AUX1 (universal), AUX2 (universal), PRE IN


ABOUT THE DM250 AMPLIFIER

After many years of trials and improvements, a design was developed whose spatial layout of individual electronic and mechanical elements allowed to obtain the shortest possible connections between elements, high resistance to interference with an excellent cooling system and thermal stability.


One of the unique design solutions used in DM250 is the HPCS (Harmonics and Phase Conversion System). It is constructed on the basis of a transistor (J-FET) system, in which thanks to precisely selected technical elements, it was possible to obtain the effect of generating even harmonics, whilst reversing the phase of the signal. The HPCS system is a solution that, introducing some subtle modifications in the spectrum and dynamics of the acoustic signal, adapts the sound of the DM250 amplifier to the subjective needs and characteristics of human hearing. This resembles to a certain extent, the effects obtained in tube amplifiers, but without the inconvenience of using lamps. In addition, the amplifier has the ability to precisely amplify the acoustic signal throughout the whole acoustic spectrum, with a perfectly sounding and dynamic low frequency range. Also, the enhancement of medium and high frequencies, with a negligible effect on phase shifts, allows the listener to hear the exact location of apparent sound sources and the effect of reproducing sound and depth plans of the sound image. Thanks to this, it is also possible to obtain the effect of a “holographic sound field” that goes far beyond the classical effects of stereophony.
DM 250 has extremely vivid and colorful sound, whose values have been very highly rated by specialists from the professional sound and sound system industry, as well as lovers of high quality audio systems.


The amplifier has a phono input for the MM cartridge, anda RIAA correction preamplifier in which the Texas Instruments integrated circuit is used, based on the JFET structure.
The RIAA curve was modified, adding an additional time constant of 3.2 uS (Neumann), thus obtaining a greater spatiality of the musical image.
The power amplifier is built as a dual mono circuit based on FET transistors. The entire signal path was designed in such a way that the user could use two parts separately, i.e. from a preamplifier or power amplifier. The disconnection of these two components takes place by means of a switch placed on the front panel. In addition, there is the possibility to directly connect the power amplifiers to the acoustic signal source.


Combination of power amplifiers with high quality sources of signal, creates extremely precise and transparent image of audio scene with accurate and detailed reproduction of tiniest sound details. The DM250 amplifier allows you to transport the listener to the real acoustic space of the music being listened to.


Read full description
View at Soundastic
Specifications

WATT RECOMMENDS

Save your favorites. Compare them anytime.

Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.

Watt'n Potatoes

Not yet rated

This product doesn't have a Watt'n Potatoes score or editorial summary yet.

WATT RECOMMENDS

Save your favorites. Compare them anytime.

Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.

Reviews & Sources

Forum Mentions

Specifications

Power
8 Ω / 2 x 130 W (CLASS AB) 4 Ω / 2 x 250 W (CLASS AB)
Minimum impedance load
1 Ω (instantaneous)
Work in class A up to
2 x 10 W
Power consumption
STATIC 40 VA – 800 VA (PEAK)
Output impedance
0.10 Ω
Distortion – THD
0.1% at 1 W / 8 Ω 0.025% at 130 W / 8 Ω
Frequency response
5 Hz – 250 kHz – 3 dB / 1 W / 8 Ω 10 – 30,000 Hz: ± 0.1 dB
Slew rate
200 V/μs
Dynamics
140 dB
Signal – noise ratio
145 dB (IHF – A)
Inputs
2 x universal – RCA XLR Amphenol separated CD / DAC – RCA phono MM – RCA input power amplifiers – RCA
Preamplifier
output – RCA
Sensitivity of inputs
500 mV – universal inputs and dedicated CD / DAC 250 mV – XLR input 3 mV – MM input 0.775 V – power amplifiers
Impedance inputs
100 kΩ; universal inputs and CD / DAC 22 kΩ XLR 47 kΩ MM 47 kΩ power amplifiers
Potentiometer (volume)
the highest precision model the Alps – Blue Velvet
Transformers
2 x toroidal, magnetically isolated 500 VA each
Capacitors filtering the supply voltage
4 x 15 000 uF – Nippon Chemi-Con
Advanced protection system
against short-circuiting of the loudspeakers and a stream of DC voltage at the output
Remote control
RC5 code (volume) The DM 250 amplifier fulfills all requirements and standards valid in the EU
Net weight
16 kg
Dimensions
430 x 102 x 338 mm
Manufacturer's warranty
24 months
Phono Stage
XLR Input
Dual Mono Design
MC/MM Switching

Manufacturer's Description — Soundastic

The harmonics and phase conversion system changes the proportions in the spectrum of harmonic distortion!


A world of music from the comfort of your own home!


STRUSS AUDIO DM 250

PRE IN SWITCH

Struss dual mono amplifier has been equipped with a PRE IN switch which means our device can act as a preamplifier and enables independent use of internal power amplifiers.


Amplifier modes: Phono, XLR, CD / DAC, AUX1 (universal), AUX2 (universal), PRE IN


ABOUT THE DM250 AMPLIFIER

After many years of trials and improvements, a design was developed whose spatial layout of individual electronic and mechanical elements allowed to obtain the shortest possible connections between elements, high resistance to interference with an excellent cooling system and thermal stability.


One of the unique design solutions used in DM250 is the HPCS (Harmonics and Phase Conversion System). It is constructed on the basis of a transistor (J-FET) system, in which thanks to precisely selected technical elements, it was possible to obtain the effect of generating even harmonics, whilst reversing the phase of the signal. The HPCS system is a solution that, introducing some subtle modifications in the spectrum and dynamics of the acoustic signal, adapts the sound of the DM250 amplifier to the subjective needs and characteristics of human hearing. This resembles to a certain extent, the effects obtained in tube amplifiers, but without the inconvenience of using lamps. In addition, the amplifier has the ability to precisely amplify the acoustic signal throughout the whole acoustic spectrum, with a perfectly sounding and dynamic low frequency range. Also, the enhancement of medium and high frequencies, with a negligible effect on phase shifts, allows the listener to hear the exact location of apparent sound sources and the effect of reproducing sound and depth plans of the sound image. Thanks to this, it is also possible to obtain the effect of a “holographic sound field” that goes far beyond the classical effects of stereophony.
DM 250 has extremely vivid and colorful sound, whose values have been very highly rated by specialists from the professional sound and sound system industry, as well as lovers of high quality audio systems.


The amplifier has a phono input for the MM cartridge, anda RIAA correction preamplifier in which the Texas Instruments integrated circuit is used, based on the JFET structure.
The RIAA curve was modified, adding an additional time constant of 3.2 uS (Neumann), thus obtaining a greater spatiality of the musical image.
The power amplifier is built as a dual mono circuit based on FET transistors. The entire signal path was designed in such a way that the user could use two parts separately, i.e. from a preamplifier or power amplifier. The disconnection of these two components takes place by means of a switch placed on the front panel. In addition, there is the possibility to directly connect the power amplifiers to the acoustic signal source.


Combination of power amplifiers with high quality sources of signal, creates extremely precise and transparent image of audio scene with accurate and detailed reproduction of tiniest sound details. The DM250 amplifier allows you to transport the listener to the real acoustic space of the music being listened to.
