Technical Highlights

• Pure Class-A, True Balanced, Fully Discrete Line Stage
• 60 Steps Microprocessor Controlled Relay Based Stepped Attenuator
• Precision Matched Through-Hole High Precision Resistors & Components with Perfect Channel Balance And Low Distortion
• Remote Controlled

Input

• IN1 - XLR1
• IN2 - XLR2
• IN3 - RCA

Output

• RCA at 2.0Vrms
• XLR at 4.0Vrms

Frequency Response: 10-80kHz（-0.3dB）

THD+N: 0.00045%

S/N Ratio: 122dB

Dynamic Range: >121dB

Stereo Crosstalk: -110dB

Input Impedance: 60k Ω

Output Impedance: 200 Ω

Gain: Unity Gain 0dB

AC Power Requirement: 110/240VAC, 50/60Hz

Power Consumption: 1W (Idle), 20W (Operational)

Dimension: 320W x 380D x 60H mm (Feet +18mm)

Weight: 9 Kg

Color: Black/Silver

Warranty: 12 Months
