What Is a Phono Stage? (And Why You Can't Skip It)
April 19, 2026
The One-Line Answer
A phono stage (also called a phono preamp) amplifies the tiny electrical signal from a turntable cartridge to line level and applies RIAA equalization to restore flat frequency response. Without one, your turntable will produce almost no sound, and what little it does produce will be thin, bright, and effectively bass-free.
This guide is part of our Phono Preamp Hub — a complete resource covering phono stages, gain, loading, RIAA equalization, and how to choose the right one for your setup.
Two Problems, One Box
When a turntable cartridge tracks a record groove, it generates a voltage — but that voltage arrives at your amplifier with two simultaneous problems: it is far too weak, and its frequency balance is deliberately wrong. A phono stage exists to solve both problems in a single box, in the correct order. Get either one wrong and the result is unlistenable.
Problem 1: The Signal Is Too Quiet
A moving magnet (MM) cartridge typically outputs 2–5 mV at a standard 5 cm/s lateral velocity. A moving coil (MC) cartridge outputs considerably less — usually 0.2–0.5 mV. A standard line-level signal, which is what every amplifier input labeled AUX, CD, or Phono/Line expects, sits in the range of roughly 200 mV to 2 V.
The arithmetic is sobering. An MM cartridge needs approximately 40 dB of gain — about 100× amplification — to reach usable line level [2]. An MC cartridge needs 55–70 dB, meaning 300–1000× amplification. Plug a turntable directly into an AUX input with no phono stage and the result is a faint, anemic whisper even at maximum volume. The signal is simply too small to drive the amplifier's input stage meaningfully.
Problem 2: The Frequency Balance Is Wrong
Beyond the gain problem lies an equalization problem. Records are not cut with a flat frequency response. During the cutting process, bass frequencies are reduced by approximately 20 dB and treble frequencies are boosted by approximately 20 dB relative to the midband [1]. This intentional distortion of the frequency balance is called RIAA pre-emphasis.
Play back a record without reversing this curve and the result is immediately obvious: the sound is thin, harsh, and almost completely devoid of bass. Treble is wildly over-represented; bass frequencies are essentially absent.
This is not a subtle coloration — it is a fundamental mismatch between how records are made and how amplifiers expect to receive a signal. Every record ever pressed requires RIAA de-emphasis on playback.
The RIAA Curve, Explained
The RIAA equalization curve exists for two engineering reasons, both rooted in the physical constraints of cutting a groove into a vinyl disc.
At low frequencies, a full-amplitude bass signal produces very wide groove excursions. Cut bass at full level and adjacent grooves risk colliding — meaning less music fits per side and the cutting stylus can jump out of the lacquer entirely. By reducing bass during the cutting process, groove width stays manageable and record playing time increases without sacrificing fidelity [3].
Rule of thumb: The RIAA curve boosts bass by roughly 20 dB and cuts treble by roughly 20 dB during playback — that's how much correction your phono stage applies on every single record.
At high frequencies, the problem is the opposite: groove noise (the surface hiss caused by the vinyl's own texture) sits in the same frequency range as quiet high-frequency program material. Boosting treble during cutting raises those high-frequency signals above the noise floor. When the phono stage then cuts treble back during playback, the music returns to its correct level — and the noise comes down with it, improving the effective signal-to-noise ratio [3].
The de-emphasis curve is defined by three RC time constants: 3180 µs (50 Hz turnover), 318 µs (500 Hz), and 75 µs (2122 Hz). These values have been standardized since 1954 and are identical worldwide.
Rule of thumb: If your turntable has a phono input labelled "PHONO" on your amplifier, it already has a built-in phono stage — connect there and skip the external preamp.
Below 500 Hz, the phono stage boosts bass to restore what was cut during recording. Above 2122 Hz, it cuts treble to remove what was boosted. Between those frequencies, the response is essentially flat.
Phono Stage or Built-In Preamp?
Many turntables — especially those aimed at beginners — include a built-in phono preamp. These typically appear as a toggle switch on the underside of the plinth or a rear-panel selector that offers a "phono" output and a "line" output. When set to "line," the built-in stage has already applied gain and RIAA correction; you connect it directly to any AUX input on your amplifier or to powered speakers.
The built-in option is genuinely convenient and perfectly functional for a first system. Use it when connecting to an amplifier or receiver that lacks a dedicated phono input, or when simplicity matters more than extracting maximum performance.
Bypass the built-in stage when your amplifier already has a dedicated phono input — using both stages in series will produce a double-equalized, over-amplified signal that sounds congested and distorted.
Tip: Connecting two phono stages in series — e.g., a turntable with a built-in stage plugged into a phono input on an amplifier — adds 40+ dB of unwanted gain and will overdrive your amp instantly.
Also consider bypassing if you want to upgrade cartridge performance beyond what the built-in stage can resolve. A dedicated external phono stage with proper gain matching and lower noise floor will extract more from a quality cartridge than any built-in unit.
Moving Magnet vs. Moving Coil
Phono stages are designed around the electrical characteristics of the cartridge they are meant to accept. The two dominant cartridge technologies have different enough output levels and impedance requirements that they need different input circuits.
An MM phono input applies 40–46 dB of gain and presents a high input impedance, standardized at 47 kΩ. This suits the 2–5 mV output and relatively high source impedance of moving magnet and moving iron cartridges. Most entry-level and mid-range phono stages are MM-only, which is fine because most beginner-to-intermediate turntables ship with MM cartridges.
An MC phono input applies 55–70 dB of gain and uses a much lower input impedance — 100 Ω is a common value, though the optimal loading varies by cartridge and should be matched to the manufacturer’s specification.
Rule of thumb: Loading affects MC cartridges, not MM. MM cartridges are standardized at 47 kΩ — if your phono stage only has a MM input, set loading to 47 kΩ and don't touch it.
Loading affects both frequency response and dynamic behavior. Too high an impedance and the cartridge sounds bright and etched; too low and it sounds dull. Getting this right is one of the key reasons serious MC users choose phono stages with adjustable loading.
Some phono stages are MM-only. Others offer switchable MM/MC inputs, sometimes with adjustable gain and impedance loading for MC.
Tip: "Switchable MM/MC" is convenient, but the best MC performance usually comes from a dedicated MC stage — the additional gain circuitry in dual-input stages is often a compromise.
A switchable stage is the practical choice if you think you might move to MC in the future — it avoids buying a second unit. The better switchable designs keep the MC gain stage separate from the MM circuit to avoid added noise.
Top-tier phono stages are often MC-optimized or MC-only, with the MM input handled by a step-down resistor network rather than a dedicated circuit. If you are certain you will always use MM cartridges, an MM-only stage will often outperform a switchable unit at the same price.
What to Look for When Buying
- MM or MC compatibility: if an MC cartridge is in your current or future system, confirm the stage supports it before purchasing. An MM-only stage cannot adequately amplify an MC cartridge.
- Gain: the stage needs sufficient gain to bring the cartridge signal to line level without clipping the output. MM cartridges require 40–46 dB; MC cartridges require 55–70 dB depending on output voltage.
- Noise floor: every phono stage adds noise, and that noise is amplified along with the signal. A signal-to-noise ratio above 70 dB is a reasonable minimum for a decent stage; better units achieve 80 dB or more [5].
- RIAA accuracy: most modern phono stages implement the RIAA curve within ±0.5 dB across the audio band [4]. Budget stages can deviate more, which translates directly to a subtly wrong tonal balance on every record you play.
- Shielding and build quality: at up to 70 dB of gain, a poorly shielded phono stage will pick up interference from nearby power supplies, transformers, or mains wiring and amplify it audibly as hum or buzz. Adequate grounding and enclosure shielding are not optional at these gain levels.
- Adjustable MC loading: if you use or anticipate using an MC cartridge, adjustable input impedance lets you match the stage to your specific cartridge's requirements rather than accepting a fixed compromise.
- Ground terminal: turntable tonearms include a separate ground wire that connects to the phono stage's chassis ground terminal to prevent hum. Most phono stages include this terminal; some budget units omit it, which can make grounding awkward.
