Wyred 4 Sound mPRE
The pre-amplifier is often the unsung hero of the music lover's audio system. Its job is to provide attenuation while remaining as transparent as possible. The existence of noise, distortion, coloration or other aural ugliness prevents your investment from meeting its full potential.
Knowing the importance of a good pre-amp, we designed our mPRE. We began by building the mPRE around fully balanced circuits that actively reject noise and lower distortion through the entire signal chain, from input to output. Then we added an analog volume control and completely seperate power supplies for the right and left channels to further remove noise, produce holographic imaging and bring out the finest details in your music. Also included is a solid performing headphone stage that offers remarkably dynamic and authoritative sound quality.
If that's not enough, this state-of-the-art pre-amp has a built-in DAC that boasts much of the technology found in our stand-alone digital-to-analog converters, making the mPRE a truly outstanding product at a very compelling price.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Watt'n Potatoes
Not yet rated
This product doesn't have a Watt'n Potatoes score or editorial summary yet.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Reviews & Sources
Online Reviews & Mentions
YouTube Reviews
No reviews found yet
Forum Mentions
No forum mentions found yet
Specifications
- Design
- Fully balanced, Dual mono design Next generation input and output buffers Built-in ESS DAC which supports 24 bit 192 kHz on all digital inputs Galvanically isolated, asynchronous USB input which supports Windows machines, is driverless for Mac, and supports Linux
- Features
- Headphone amplifier Remote Control 12V DC trigger input and output Efficient (no heat) Fully balanced input to output Discrete input and output buffers Unbalanced to balanced conversion (when RCA input selected and XLR outputs are being used) Robust construction Machined and anodized aluminum front panel, top, and sides
- Inputs and Outputs
- 100kΩ input impedance 1 set of balanced (XLR) inputs 1 set of balanced (XLR) outputs 2 sets of unbalanced (RCA) inputs (one is selectable as HT bypass) 2 sets of unbalanced (RCA) outputs (one is selectable as a fixed 2.0V output) Home Theater Bypass
- Performance
- Typical THD+N 20Hz-20kHz (A Wt) @ 2V: <0.002% Noise 20Hz-20kHz (A Wt): < 12µV Frequency Response 20Hz-20kHz: ± 0.020db Channel Tracking: < ± 0.020db Crosstalk: > 95db Input Impedance: 100kΩ Output Impedance: 100Ω S/N Ratio: > 103db Gain: 11.4db
- RCA In/Out
- Typical THD+N 20Hz-20kHz (A Wt) @ 2V: <0.007% Noise 20Hz-20kHz (A Wt): < 8µV Frequency Response 20Hz-20kHz: ± 0.002 db Channel Tracking: < ± 0.020 db Crosstalk: > 118 db Input Impedance: 100kΩ Output Impedance: 100Ω S/N Ratio: > 105 db Gain: 5.3 db
- Digital In/XLR Out
- Typical THD+N 20Hz-20kHz (A Wt) @ 2V: <0.006% Noise 20Hz-20kHz (A Wt): < 12µV Frequency Response 20Hz-20kHz: ± 0.002 db Channel Tracking: < ± 0.020 db Crosstalk: > 118 db Input Impedance: 75Ω (Coax) Output Impedance: 100Ω S/N Ratio: > 105 db Gain: 17.2 db (Vrms/FS)
- Headphone Output
- 32Ω Load: 1.3W @ 0.1% THD+N 300Ω Load: 255mW @ 0.1% THD+N 600Ω Load: 128mW @ 0.1% THD+N
- Warranty
- Covered by a 5 YEAR WARRANTY
Manufacturer's Description — Wyred 4 Sound
The pre-amplifier is often the unsung hero of the music lover's audio system. Its job is to provide attenuation while remaining as transparent as possible. The existence of noise, distortion, coloration or other aural ugliness prevents your investment from meeting its full potential.
Knowing the importance of a good pre-amp, we designed our mPRE. We began by building the mPRE around fully balanced circuits that actively reject noise and lower distortion through the entire signal chain, from input to output. Then we added an analog volume control and completely seperate power supplies for the right and left channels to further remove noise, produce holographic imaging and bring out the finest details in your music. Also included is a solid performing headphone stage that offers remarkably dynamic and authoritative sound quality.
If that's not enough, this state-of-the-art pre-amp has a built-in DAC that boasts much of the technology found in our stand-alone digital-to-analog converters, making the mPRE a truly outstanding product at a very compelling price.
