Trafomatic Audio Luna
Luna tube phono preamplifier is top class product in Trafomatic Audio production .
The main advantage is that this preamplifier use very rare LCR method to apply the RIAA correction due to complexity and cost.
There are a total of only the finest components such as four C3g SE tubes connected in triode mode , two interstage and two line output transformers as well as LL1941 input MC step up .
This preamplifier also applies the separately executed power supply used low induction toroidal transformer as well as two high inductivity chokes and Mundorf MLytic HV electrolytic capacitors .
Luna features :
- Built in step up transformers
- Switches ground plane with input selection preventing ground loops
- Balanced and unbalanced output
- Separate low impedance CLC power supply
Luna uses two tube gain stages with zero feedback and passive LCR equalizer .
The input stage as well as output is low noise Siemens c3g German Post tubes used in triode connection. Every stage is loaded by transformers and this provide complete isolation of this sensitive circuit from the following components.
There are no capacitors in signal way except in RIAA correction where we used Silver mica ones.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Watt'n Potatoes
Not yet rated
This product doesn't have a Watt'n Potatoes score or editorial summary yet.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Reviews & Sources
Online Reviews & Mentions
YouTube Reviews
No reviews found yet
Forum Mentions
No forum mentions found yet
Specifications
- Amplifier Type
- Single-ended Class A
- Power Supply
- Separate power supply
- Gain
- MM – 45 dB, MC – 70 dB using input transformers LL1941 (uncut amorphous cobalt core, Cardas high purity copper wire)
- Noise and Hum
- -78 dB
- Output Voltage
- 1.0Vrms
- Inputs
- MM (RCA) – 47k MC (RCA)
- Adjustable MC Inputs
- 10ohms, 20 ohms, 50 ohms, 100 ohms
- Output Impedance
- 660 Ohms, XLR and RCA
- Frequency Response
- RIAA Curve +/- 0.4 dB
- Vacuum Tube Complement
- 4 x C3g SE
- Power Supply
- Low Induction toroid transformer by Trafomatic Audio, High Inductivity custom made chokes, Mundorf MLytic HV type
- Requirements
- 100, 117 or 240 Volts / 50-60 Hz, 60 watts
- Weight
- 10 kg
- Dimensions
- 400x 310 x 85mm (two box)
Manufacturer's Description — Trafomatic Audio
Luna tube phono preamplifier is top class product in Trafomatic Audio production .
The main advantage is that this preamplifier use very rare LCR method to apply the RIAA correction due to complexity and cost.
There are a total of only the finest components such as four C3g SE tubes connected in triode mode , two interstage and two line output transformers as well as LL1941 input MC step up .
This preamplifier also applies the separately executed power supply used low induction toroidal transformer as well as two high inductivity chokes and Mundorf MLytic HV electrolytic capacitors .
Luna features :
- Built in step up transformers
- Switches ground plane with input selection preventing ground loops
- Balanced and unbalanced output
- Separate low impedance CLC power supply
Luna uses two tube gain stages with zero feedback and passive LCR equalizer .
The input stage as well as output is low noise Siemens c3g German Post tubes used in triode connection. Every stage is loaded by transformers and this provide complete isolation of this sensitive circuit from the following components.
There are no capacitors in signal way except in RIAA correction where we used Silver mica ones.
