Trafomatic Audio Elegance Evolution
The Elegance Evolution stereo push -pull integrated amplifier is a successor of highly regarded and awarded Experience Elegance integrated amplifier.
Both, the design and topology follows natural progression and highest demands of the high end audio market.
State of the art, no—compromise power supply and oversized output transformers (wound on Double-C cores) characterize the Elegance Evolution integrated amplifier as another definitive audiophile product.
Description: The Elegance Evolution integrated amplifier combines the output stage of our most powerful Evolution series amplifier with input switching and a passive buffered attenuator (ALPS) driven by remote control.
The class AB power stage in ultra-linear mode produces 50 watts per channel from a quartet of push-pull connected 6550 (KT88). Manual setting of bias of each 6550 is new feauture and give possibility to adjust bias on even no matched output tubes.
A small amount of cathode feedback lowers the output impedance and ensure excellent bass control and dynamics. All new power supply greatly benefits from an oversized, proprietary Trafomatic Audio 300VA toroidal transformer, C-L-C filtering and Rubycon electrolytic capacitors.
Excellent sound was achieved with the high-quality double C-core output transformers and exclusive Solen (fast caps) in the signal path.
Elegance Evolution integrated amplifier was designed from ground up to satisfy both demanding audiophiles and music lovers. It can drive speakers from 88dB with authority, refinement and emotional impact.
Elegance Evolution brings potent and emotional involving performance in a premiere package and at best value.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Watt'n Potatoes
Not yet rated
This product doesn't have a Watt'n Potatoes score or editorial summary yet.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Reviews & Sources
Online Reviews & Mentions
No reviews found yet
YouTube Reviews
No reviews found yet
Forum Mentions
No forum mentions found yet
Specifications
- Output power
- 2x50W
- Class of operation
- Push-Pull (class AB)
- Tubes complement
- 4x 6550 Tungsol , 2x ECC82 , 2x ECC81
- Inputs
- 4x RCA
- Outputs
- 4 – 8 ohms
- Input sensitivity
- 0.8 Vrms
- THD %
- 0.03% – 1W/1KHz, 3% –50W/1KHz
- Frequency bandwidth
- 10Hz(-1dB) – 45KHz( -3dB)
- S/N Ratio
- 84dB
- Input inpedance
- 100K
- Power consumption
- 250VA
- Input voltage
- 230V/50Hz( 100-120-220-240V available on request)
- Size
- 450x320x195mm
- Weight
- 22kg
