Sonic Excellence Hidden Neatly Inside Your Ceiling

Prepare to experience sonic immersion and accuracy like you’ve never heard before from an angled in-ceiling speaker. The Tribe Architectural AIC will bring a true sense of realism to your favourite musicians and Hollywood blockbusters, creating vast three dimensional soundscapes in your room. Like all Totem speakers, this in-ceiling speaker is forgiving in terms of placement and designed to blend seamlessly with other Totem speakers so that no matter where you install them, you will be rewarded with incredible sound. All you will need is a snack, a drink and a comfortable seat!

The Tribe Architectural AIC speaker is one of the most advanced in-ceiling speakers in the world, taking advantage of the lessons learned from the development of Totem’s high-end Element speaker series. The remarkable engineering of this speaker allows it to rival the performance of the best in-wall speakers in the market, which is no easy feat. Unlike traditional in-ceiling speakers that make you look up because the sound is obviously coming from the ceiling, Tribe Architectural AIC brings the sound down to your ear level, whether you are sitting down or standing up.

The Tribe Architectural AIC is designed to integrate seamlessly with our in-wall subwoofers: the Tribe In-Wall Sub 12 and Tribe Sub In-Wall Sub Double 8. Our Tribe Solution Sub is also a perfect match for the Tribe Architectural AIC.

Optional Accessories

Pre-construction kits facilitate installation before drywall has been installed.

Design Highlights

• Immersive, accurate sound no matter where you sit in the room
• Seamless sonic integration between all speakers, regardless of installation location
• Higher performance compared to most in-wall speakers in the market
• Utilizes technology borrowed from Totem’s high-end Element speaker series
• Sophisticated 1-1/8” tweeters feature Mundorf domes, massive Neodymium magnets and precision machined faceplates
• 4” Neodymium Actuated MHEX woofers feature multiple layers of phenolic honeycomb and woven synthetics, imported from Japan, that are extremely rigid. Inverted dust caps smooth out the higher frequencies for a perfect blend with the tweeters
• 5” passive radiators are made of a proprietary compound of metals chosen for their strength to weight ratios. They are unyieldingly rigid yet perfectly weighted, so bass is both forceful and musical
• Hand-assembled crossovers are constructed using the finest available parts from around the world that far surpass the quality of parts used by competing products. Highlights include exotic capacitors from Mundorf, Rel-Cap and ClarityCap, military-grade resistors from Ohmite, as well as silver and oxygen-free copper wiring
• Angled baffle allows placement tight to walls while directing sound to the listening area
• Screw cutouts in the framework for flush-to-stud installations where clamps cannot deploy
• High-torque angled wall clamps for an even structural tension
• Rear-wire management channels
• Integrated wood back box ensures reliable and superior performance

Integrated Wood Back Box

Integrated back boxes ensure optimum performance regardless of the wall cavity size or content. Wherever they are installed, they react as if the wall was custom made for them. Metal, plastic, or aluminum enclosures have inherent distortion issues that wood does not. Back boxes also provide substantial sound isolation and protect against materials in the wall that can damage the drivers.

Enormous Dispersion

TRIBE Architectural diffuse sound in an enormously wide, expansive manner comparable to a flood light and illuminate a room with Totem’s holographic sound. Most others function like a focused, narrow spotlight, creating small acoustic “hot spots”. The dispersion is almost twice that of competitive speakers, so it takes fewer Totem speakers to thoroughly fill a room, and listeners enjoy the same sound whether seated or standing.

Neodymium Actuated Enriched MHEX woofers

Multiple layers of phenolic honeycomb and woven synthetics are extremely rigid, have sensational transient capabilities, and a pure, flat response in the critical 100Hz to 2.5kHz range. These cones are enriched with a proprietary copolymer that improves strength without adding weight. An inverted dust cap smooths the higher range for a perfect blend to the tweeter. Outsized cast frames resonances allow the largest components tot be implemented for improved force and control. The result is tremendous power handling and incredible bass.

Oversized Silk Dome

The 1 1/8” proprietary dome was designed specifically to mate with Neodymium Actuated Enriched MHEX woofers. It possesses excellent dynamic response, high stability, and can be crossover extremely low for improved dispersion. It is particularly effective in the D’Appolito arrangement of all Tribe models. A remarkable low resonant frequency and Ferro fluid of high liquidity create an effortless brilliance.

Metal Amalgamation Passive Radiators

5” passive radiators are made of a proprietary compound of metals chosen for their strength to weight ratios. They are unyieldingly rigid yet perfectly weighted, so bass is both forceful and musical. These passives function in tandem with the MHEX drivers to tune the sealed enclosure to perfection with size defying bass output.

Connectors

Two sets of high conductivity gold plated connectors efficiently capture the incoming signal for superior speaker performance and allow traditional, bi-wire, or even bi-amplification options. They accommodate a variety of connection options such as bare wire, banana plugs, and spades.
