Pro-ject Audio Systems - USA Tube Box DS3 B
The Tube Box DS3 B brings an open, engaging vinyl presentation to systems that demand precision. TECH REVIEWS highlights its exemplary ability to expand recorded sound, while 40–65dB gain, continuously adjustable MC loading and balanced XLR output make this a highly flexible phono stage for tailoring MM or MC cartridges.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
Nicely Roasted
Sound Quality
85/100
Cartridge Compatibility
91/100
Build Quality
80/100
Value for Money
85/100
Pros
Opens up vinyl playback with an especially engaging, spacious overall presentation.
Flexible, user-friendly phono-stage design.
WATT RECOMMENDS
Save your favorites. Compare them anytime.
Create a free HiFi Hub account to save products to your Wishlist and compare your favorites side by side.
What Reviewers Are Saying
SOUND QUALITY PERFORMANCE 85/100
The available review offers a notably positive overall impression, saying the Tube Box DS3 B opens up vinyl playback in exemplary fashion. It provides little detail on noise, dynamics, tonal shading, or imaging individually, so those aspects remain less clearly documented.
Transparency Noise Floor
85/100
The review's comment that the unit opens up records suggests a clear and revealing presentation. However, it does not directly discuss hum, hiss, background silence, or performance with low-output moving-coil cartridges; the published specification lists a signal-to-noise ratio above 87 dBV.
Tonal Balance Musicality
89/100
The reviewer describes the Tube Box DS3 B as opening up the sound of vinyl in exemplary fashion, an especially encouraging verdict on its overall musical presentation. There is no more specific description of whether its balance is warm, neutral, rich, or analytical.
Dynamics
83/100
The broadly enthusiastic listening comment indicates that the phono stage brings more life and openness to records. The review does not specifically address transient attack, bass punch, microdynamic shading, or rhythmic drive.
Soundstage Imaging
83/100
An ability to open up vinyl playback can be consistent with a more spacious presentation. Still, the review gives no direct account of image focus, stage width, depth, or layering.
Assessments of Build Quality, Usability, and Overall Propositions.
Cartridge Compatibility
91/100
This is a highly adjustable MM/MC design, with gain selectable from 40 to 65 dB, continuously variable MC loading from 10 to 1,000 ohms, fixed 47k-ohm MM loading, and four capacitance settings. RCA and balanced XLR connections further broaden its usefulness, although the review does not report on setup with particular cartridges.
Build Quality
80/100
The published design includes balanced and single-ended connectivity, a dedicated external DC supply, and switchable settings appropriate to a serious phono preamplifier. Reviewers say little about casework, shielding effectiveness, internal layout, control feel, or long-term durability.
Value for Money
85/100
No selling price is provided, and the available review does not compare the Tube Box DS3 B with competing phono stages or assess whether its performance justifies its cost. Its extensive gain, loading, capacitance, and balanced-output provision are substantial features, but the available evidence does not establish its value against similarly priced alternatives.
Reviews & Sources
Professional reviews and sources for this product's Watt'n Potatoes analysis.
Online Reviews & Mentions
YouTube Reviews
No reviews found yet
Forum Mentions
No forum mentions found yet
Specifications
- Tube assembly
- 2x E88CC / 6922
- Input impedance
- stepless 10-1000 Ohms, fix 47 kOhms
- Capacitance
- 50 / 150 / 300 / 400 pF
- Gain (+6dB using XLR Out)
- 40 / 45 / 50 / 55 / 60 / 65 dB
- Output voltage typically
- 500 mV/1kHz at 5mV/1kHz (at 40dB)
- Signal-to-noise ratio
- >87dBV - ‚A‘ weighted
- THD
- < 0,03%
- RIAA curve accuracy
- +/- 0,5dB/20Hz - 20kHz
- Subsonic filter
- at 20Hz with 18dB/octave
- Input
- 1x 5-pin mini XLR / 1x pair XLR / 1x pair RCA phono
- Output
- 1x pair RCA, 1x pair XLR
- Power supply
- 18V/1000mA DC
- Power consumption
- max 750 mA DC / < 0,5 watt standby
- Dimensions W x H x D
- 206 x 70 x 194 mm
- Weight
- 1560g (without power supply)
Manufacturer's Description — Pro-ject Audio Systems - USA
Dual mono balanced tube phono-preamplifier
Made In Europe
High-end tube sound
The Tube Boxes have been an integral part of our product portfolio for many years. Now, the new Tube Box DS3 B adds balanced in- and outputs to the beloved tube amplification. This precision tube phono preamplifier benefits from outstanding circuit technology from Dr. Sykora and uses ultimate components.
Cartridge loading options
You can connect two turntables at the same time & easily set everything on the front plate. Each input settings are stored in the memory. Large ranges from 40dB up to 65dB are possible. You can perfectly match it with a wide variety of cartridges and integrate it into the rest of your Hifi system, matching the volume levels accurately to other sources like CD players or streaming devices. Load impedance can be set continuously via potentiometer, a system invented by Pro-Ject Audio Systems. It allows you to seamlessly adjust the impedance during playback and immediately assess the impact of different loading options. This is necessary to find just the right load impedance for your cartridge. No other manufacturers implement this feature in this extreme way.
Balanced XLR
Interference free
A balanced connection can extract the final musical information, effectively filtering out any noise from interferences stemming from our noisy, modern homes.
E88CC
Vacuum tubes
The E88CC tubes perform with low noise and microphonics. Enjoy the detailed low end paired with warm highs.
Settings
Continously impedance loading
Load impedance can be set continuously via potentiometer. It allows you to seamlessly adjust the impedance during playback
Made in EU
High-quality materials
The new Tube Box DS3 B is carefully designed and handmade in Europe.
