Deep, powerful bass in an elegant design - the perfect subwoofer for intense music and home theater experiences.

The closed housing ensures precise bass reproduction with high control, while the adjustable crossover frequency and phase position enable seamless integration into any stereo or home theater system. With its elegant surface and robust construction, the Omega CS 12 noticeably adds more pressure and depth to your sound system.

The Omega CS 12 combines deep, room-filling bass with an elegant, understated design. The bevelled housing blends harmoniously into any living environment, while the compact footprint enables flexible placement even in smaller rooms.

A front display that clearly shows the volume and settings ensures additional ease of use. In addition, the subwoofer comes with its own remote control, with which the performance can be conveniently adjusted from the listening position.

Thanks to the 1,100-watt Class D amplifier and the 12″ / 30 cm long-throw driver, the Omega CS 12 delivers clean, punchy low frequencies for films and music. The front radiation ensures direct, room-filling bass distribution and at the same time enables flexible placement - even close to walls or furniture without compromising sound quality.

With intuitive controls and remote-controlled volume control, setup is very easy: connect, adjust and enjoy.

From the closed housing to the ESD-insulating feet, every detail is optimized for precise, distortion-free bass. Developed and designed in Germany, the Omega CS 12 stands for high-performance sound with the reliability and quality of workmanship for which Magnat is known.

OUR TECHNOLOGIES

CLOSED HOUSING FOR PRECISE, POWERFUL BASS

Housed in a closed housing, the Omega CS 12 delivers fast, controlled bass with exceptional impulse fidelity - ideal for music and home cinema applications where precision and punch are crucial.

The closed design also prevents flow noise and ensures particularly clear reproduction. With a deep bass reproduction down to 18 Hz, the Omega CS 12 gives films, games and music impressive depth and superior authority.

ADVANCED TUNING FOR PERFECT INTEGRATION

For optimal integration into a wide variety of audio systems, the Omega CS 12 offers extensive fine-tuning options. These include an adjustable low-pass crossover (50–150 Hz), a continuously adjustable phase adjustment from 0° to 180° and precise level control. This allows the performance of the subwoofer to be perfectly matched to room acoustics and main loudspeakers.

An automatic on/off function with signal detection saves energy by only activating the subwoofer when an audio signal is present. This makes the Omega CS 12 both powerful and efficient - ideal for demanding home cinema and music systems.

DEVELOPED FOR DEEP, POWERFUL BASS

The Magnat Omega CS 12 is equipped with a powerful 12″/30 cm long-stroke woofer that was developed for deep and precise bass. Its advanced magnet system and specially reinforced diaphragm are designed to effortlessly process even very low frequencies - for a rich and detailed sound.

The wide surround with stable stitching ensures high load capacity and durability, while the ventilated voice coil with aluminum support reliably cools the system even at high volumes. A solid die-cast aluminum basket forms the stable base and minimizes vibrations - for a clean, powerful performance.

PERFORMANCE AT A GLANCE

Principle:

Active closed subwoofer (front fire)

Output power:
525 Watt RMS / 1.100 Watt Peak

Equipped with:

30 cm (12”) powered woofer

Frequency response:
18 – 200 Hz

Crossover frequencies:

50 – 150 Hz

Phase:

0° – 180° adjustable

Dimensions (H × W × D):

38,5 × 40 × 46,5 cm (including amplifier)

Weight:

24 kg

Color:
Satin black
Satin white

DOCUMENTS FOR DOWNLOAD

Operating instructions

Data sheet

Safety data sheet
