BTA30

Name: FiiO BTA30
Brand: FiiO
SKU: fiio-bta30

FiiO BTA30

View at FiiO

Bluetooth

LDAC

Built-in DAC

aptX HD

BTA30

High Fidelity

Bluetooth Transceiver

Qualcomm CSR8675 Bluetooth chip

AK4490 DAC | High-performance DSP

3 operating modes | Bluetooth 5.0

Transmit and receive LDAC | 30m range

RGB indicator | APP remote control

Bringing you essential joy

iLife mustn’t be all work and no play. It is essential to recharge and rejuvenate with music and entertainment every so often. Whether it’s an old speaker gathering dust in the living room or that game console neglected in the corner, there are brand new ways to connect to these to give you much-needed private and exciting experiences.

High-definition Bluetooth for higher heights of joy

High-definition Bluetooth formats cover a wider range and have faster transmission rates for a more exhilarating experience!

A truly versatile device

The BTA30 with its 3 operating modes is also the first such desktop decoding system to support bidirectional LDAC/aptX HD Bluetooth. It can greatly improve the sound of audio equipment such as your TVs, speakers, and computers to spice up your life.

2. Bluetooth transmitter-TX

Get cinema-grade sound anywhere in the home. Connect the digital output of the TV/CD player/ computer to the BTA30, which can then transmit to your Bluetooth headphones for a truly cinematic listening experience.

*LDAC/aptX HD/aptX LL/SBC formats supported; LDAC is supported only through optical/coaxial input, not through USB

3. Digital decoding-DAC

If not using Bluetooth, there is also excellent audio output! The BTA30 can be used as a DAC to convert digital audio to high-quality analog signal.

*Coaxial input supports up to 24 bit/192kHz and native DSD64; optical input supports up to 24 bit/96kHz; USB input supports up to 16 bit/48kHz.

*The coaxial and optical output only works when there is USB input.

1. Bluetooth receiver-RX

Revive your old music setup at home with just one move! In Bluetooth receiver mode, connect your phone/music player to the BTA30 via Bluetooth, and the BTA30 to your non-Bluetooth music system – allowing your old setup to play wireless music. *Supports LDAC/aptX/aptX HD/AAC high-definition Bluetooth formats

Easy to use, easy to enjoy

Rejuvenate vintage speakers

Computer audio assistant

What happens if an older amplifier/speaker doesn't have Bluetooth for wireless, hassle-free music? Simply connect the RCA output of the BTA30 to the RCA inputs of the amplifier/speaker – now you can play your music over Bluetooth through your older amplifier/speaker, giving it new life!

Get great sound from your computer too! With the USB DAC functionality, transmit high quality sound from your computer to speakers or Bluetooth headset through the BTA30.

Decoder for your Bluetooth jukebox

Exciting gaming

(game console-TV-headset)

Full theater immersion

Want to directly connect your DAC/audio decoders to any smartphone? Simply connect the optical/coaxial out of the BTA30 to the digital input of your external DAC to allow it to decode directly from your phone.

Connecting the BTA30 to your TV’s SPDIF/optical out allows you to send low-latency sound to your Bluetooth headset, allowing you to be fully immersed in your own private theater.

You need to fully enjoy any gaming session you get! By connecting your game console via optical out to the BTA30, you can directly send wireless sound to your Bluetooth headset via the BTA30 for more enjoyable gaming.

Turn on dual device mode

Want to share with someone else? No problem! Under Bluetooth receiving mode, the BTA30 can connect to and remember two devices at once, allowing your access to your favorite music in both. Under Bluetooth transmitting mode, the BTA30 can send signals to two Bluetooth headsets at once.

A+ specs with

competitive performance

· Qualcomm CSR8675 Bluetooth chip

The BTA30 utilizes the efficient Qualcomm CSR8675 Bluetooth chip for enhanced audio applications – supporting 24-bit audio processing and equipped with a 120MHz DSP, it effectively integrates various Bluetooth decoding functions into one package.

· High-performance AK4490 DAC

Responsible for digital-to-analog conversion is the AK4490, allowing up to 384kHz and DSD native decoding. Its implementation here lets you easily hear every small detail in your music, and provides higher SNR and dynamic range than with the Bluetooth build-in DAC and with better DAC than similar transceivers. Film capacitors work with the AK4490 for clearer and more transparent treble.

Good sound everywhere

With the BTA30, you can easily create a comprehensive home Bluetooth system. The BTA30 utilizes an external gain antenna for Bluetooth connections resulting in faster connection speeds, more stable signals, and for longer distance transmission across rooms – up to 30 meters under normal conditions.

Passionately smooth and suave

The strong aluminum alloy body gives the BTA30 a luxurious shininess along with a silky-smooth texture. The neat and uniform button arrangement makes it easy to use, and coordinates well with other audio equipment.

Innovative volume control for fast, accurate adjustment

The BTA30 is among the first Bluetooth desktop devices to incorporate pro-level audio volume adjustment methods.

Innovation 1: No imbalance, precise control through ADC curve reconstruction

Innovation 2: Can quickly adjust both analog and digital output volume

Innovation 3: Can be remotely controlled through FiiO Music APP

Innovation 4: Fixed output volume setting is available through FiiO Music APP

*When transmitting out from USB DAC input, the volume cannot be adjusted.

Convenient intelligent interaction

Your smartphone, when connected to the BTA30, can remotely control it via the FiiO Music or FiiO Control APP to make your life easier.

1. Channel balance

2. 4 types of audio filters

3. Bluetooth format priority

4. Switch on/off LED indicator

5. Volume adjustment

6. Set fixed output volume

Dual Hi-Res Certifications

Not only does the BTA30 have Hi-Res Audio certification by the Japan Audio Society, it also has achieved Hi-Res Audio Wireless certification for guaranteed excellent performance.
