Charisma Audio YYZ Moving Coil Cartridge

• Cartridge Weight: 8 g
• Cartridge body: yellow rosewood
• Cantilever: diamond
• Stylus: micro fine line contact diamond
• Vertical Tracking Angle: 20 degrees
• Coil: pure iron square coil with custom made alloy wiring
• Output Voltage: 0.35 mV at 3.54 cm/sec.
• Internal Impedance: 6 ohms
• Frequency Response: 20 – 30,000 Hz ± 1 dB
• Channel Balance: better than 0.5 dB
• Channel Separation: better than 30 dB
• Dynamic Compliance: 10 um/mN
• Recommended Loading: 100 – 330 ohms
• Recommended Tracking Force: 1.4 g ± 0.1 g
• Optimum Tracking Force: 1.45 g
• Tracking Ability at 315 Hz / 2 g: 80 uM
• Recommended Tonearm Mass: medium
• Break-in Period: 50 hours
