Reference Two Moving Coil Cartridge

Charisma Audio Reference Two Moving Coil Cartridge

Output Voltage: 0.38 mV at 3.54 cm/sec
Coil: Special iron crossed-coil with extremely high purity and ultra fine single crystal copper
Cantilever: Ruby
Stylus: Super fine line contact nude diamond
Vertical Tracking Angle: 20 degrees
Internal Impedance: 12 ohms
Recommended Loading: 100 – 1,000 ohms
Dynamic Compliance: 15 um/mN
Frequency Response: 20 – 25,000 Hz ± 1 dB
Channel Balance: better than 0.5 dB
Channel Separation: better than 30 dB
Cartridge Body: Bocote Wood
Cartridge Weight: 7.1 g
Recommended Tracking Force: 2.0 g ± 0.1 g
Tracking Ability at 315 Hz / 2 g: 80 uM
Recommended Tonearm Mass: medium
Break-in Period: 50 hours
