Reference One Moving Coil Cartridge
Charisma Audio Reference One Moving Coil Cartridge
- Cartridge Weight: 7.1 g
- Cartridge Body: amboyna burl wood
- Cantilever: ruby
- Stylus: super fine line contact nude diamond
- Vertical Tracking Angle: 20 degrees
- Coil: pure iron crossed-coil with ultra high purity single crystal copper
- Output Voltage: 0.42 mV at 3.54 cm/sec.
- Internal Impedance: 14 ohms
- Frequency Response: 20 – 25,000 Hz ± 1 dB
- Channel Balance: better than 0.5 dB
- Channel Separation: better than 30 dB
- Dynamic Compliance: 10 um/mN
- Recommended Loading: 100 – 1,000 ohms
- Recommended Tracking Force: 2.0 g ± 0.1 g
- Tracking Ability at 315 Hz / 2 g: 80 uM
- Recommended Tonearm Mass: medium
- Break-in Period: 50 hours
