STREAMER / DAC

Whether you’re listening to high-definition streaming music locally from your network, from a USB key, a hard drive, Bluetooth®, or your favourite internet radio stations, our mini network player MS120 is adapted to the current needs related to reading dematerialized music files. It embeds a high-performance converter and can be used as a pure source or preamplifier.

• 4 mm brushed aluminium front.
• 2 transformers 5 VA + 1×3.2 VA + 1×4.6 VA (audio stages).
• High-quality MKP technology link capacitors.
• BURR-BROWN PCM1796 converter:
           – Dynamic: 123 dB.
           – Signal/Noise ratio: 123 dB.
• 5″ TFT LED colour graphic display (800*480).
• Discrete component audio stages without negative feedback in pure Class A.
• Analogue volume management (switched resistors) that can be bypassed.
• A specific power supply is dedicated to the audio stages.

• A specific power supply is dedicated to the digital audio line converter.
• Accepted resolutions: PCM up to 24 bits/192 kHz and DSD64 and DSD128.
• Playback of audio files on the network (DLNA and UPnP compatible)
        in a wired RJ45 or Wi-Fi connection.
• Display of names, tags, resolutions and album covers.
• “Gapless” system (no cut between pieces).
• Ability to create playlists.
• USB-A file systems: FAT32, NTFS, EXT2/3/4.
• ATOLL “streamer” remote control supplied as standard.
• “ATOLL Signature 2” App (Android and IOS).

CONNECTIVITY

Audio inputs
2 Stereo line inputs.
4 Digital inputs: 2 Coaxial, 2 Optical.
1 Bluetooth® 4,2 input.
2 USB-A inputs (1 front, 1 rear).

Audio outputs
1 Stereo line output.
2 Digital outputs: 1 Coaxial, 1 Optical Toslink.

Various
1 RJ45 input (network).
1 Trigger output (12V).
1 WIFI antenna (802.11b/g/n).
1 Bluetooth® antenna.
