Power handling : 100 W Rms after filtering

Peak power : 300 W Max after filtering

Sensitivity : 98 dB/2.83V/1m

Impedance : 4 ohms

DC resistance : 3.6 ohms

Resonance frequency : 1200 Hz

Le : 0.003 mH

Sd : 6.6 cm²

Coil diameter : 28 mm

Coil height : 1.5 mm

Air gap height : 2 mm

Flux density : 17000 gauss

Linear excursion : +/- 0.25 mm

Recommended roll off frequency : 2500 Hz
