Power handling : 150 W Rms
Peak power : 300 W Max
Sensitivity : 93 dB/2.83V/1m
Impedance : 4 ohms
DC resistance : 3.6 ohms
Resonance frequency : 46 Hz
QTS : 0.32
QES : 0.35
QMS : 3.94
CMS : 0.66 mm/N
MMS : 18.2 gBL : 7.2 N/A
Le : 0.58 mH
Sd : 160 cm²
Coil diameter : 35 mm
Coil height : 18 mm
Air gap height : 6 mm
Flux density : 11200 gauss
Linear excursion : +/- 7.5 mm
Maximum excursion : +/- 11 mm
Recommended roll off frequency : 2500 Hz
